Name: PVC pipe belling machine with four station / double cavities / single head station for U type and R type
Brand: Shenzhen HYPET Co., Ltd.
SKU: belling socketing machine
Price: 21,000.00 USD
Availability: InStock

Home > products > Auxiliary Machine and Parts >

PVC pipe belling machine with four station / double cavities / single head station for U type and R type

PVC pipe belling machine

Place of Origin:

China

Brand Name:

Hypet

Certification:

ISO9001,CE

Model Number:

belling socketing machine

Request A Quote

PVC pipe belling machine with four station / double cavities / single head station for U type and R type

Product Details

Key Parts Warranty:

1year

Engineer Installation Service:

Yes

Applicant For:

PE PPR

Station:

Single / Double

Highlight:

PVC pipe belling machine

Payment & Shipping Terms

Minimum Order Quantity

1set

Price

USD 9000-33000/set

Packaging Details

Standard Package for sea shipment

Delivery Time

35~45days

Payment Terms

L/C, T/T

Supply Ability

50set/month

ryan@hypet.com.cn

+86-755-25851030

Contact Now

Product Description

1.Belling socketing machine
PVC pipe belling machine with four station / double cavities / single head station for U type and R type 0

2.HYPET Special features

1). Applied for sewerage and pressure pipes etc.

2). Heating by inner and outer heaters make pipes get even and perfect heating.

3). PLC control for completely automatic working.

4). Easy and convenient for operation, control system friendly

5). High output and low consumption

3.Commercial items

SN	Item	Qty	Unit Price	Total Price
1	Belling socketing machine HYK32-4	1	9000		9000
2	Belling socketing machine HYK63-2	1	9400		9400
3	Belling socketing machine HYK110	1	7700		7700
4	Belling socketing machine HYK160	1	8700		8700
5	Belling socketing machine HYK250	1	10000		10000
6	Belling socketing machine HYK400	1	18200		18200
7	Belling socketing machine HYK500	1	23400		23400
8	Belling socketing machine HYK630	1	33000		33000

					USD/SET EXW

4.Main Specification of the Machine

Model	HYK32-4	HYK63-2	HYGK110	HYGK160
Cavity	Four pipe	Two pipe	One pipe	One pipe
Pipe sizes	16-32	16-63	50-110	50-160
Heater oven	Single	Single	Single	Single
Pipe length	3-4m	4-6m	4-6m	4-6m
Heating power	7kw	7kw	8.5kw	8.5kw
Cooling type	Air + water	Air cooling	Air cooling	Air cooling
Belling type	U type	U type	U & R type	U & R type
Belling way	Air pressure	Hydraulic	Hydraulic	Hydraulic
Total power	15kw	15kw	15kw	15kw
Overall dimensions	520015701500mm	550015701500mm	7140×1420×1800mm	7140×1420×1800mm

Model	HYGK250	HYGK400	HYGK500	HYGK630
Cavity	One pipe	One pipe	One pipe	One pipe
Pipe sizes	63-250	160-400	250-500	315-630
Heater oven	Single	Double	Double	Double
Pipe length	4-6m	4-6m	4-6m	4-6m
Heating power	12kw	12kw*2	14kw*2	16KW*2
Cooling type	Air cooling	Water cooling	Water cooling	Water cooling
Belling type	U & R type	R type	R type	R type
Belling way	Hydraulic	Hydraulic	Hydraulic	Hydraulic
Total power	20kw	35kw	45kw	55kw
Overall dimensions	7140×1420×1800mm	7600×2200×2300mm	8500x2850x2200mm	8710x3260x2800mm

5.Cooperative Brands:

6.Exhibition:
